queue base class. More...

#include <queue.hpp>

Public Types
using	ValueType = Type

Public Member Functions
template<typename... Args>
	BasicQueue (uint64_t capacity, Args &&... args)
	create instance.

	BasicQueue (const BasicQueue &other)=delete
	copy constructor.

BasicQueue &	operator= (const BasicQueue &other)=delete
	copy assignment operator.

	BasicQueue (BasicQueue &&other)=delete
	move constructor.

BasicQueue &	operator= (BasicQueue &&other)=delete
	move assignment operator.

	~BasicQueue () noexcept=default
	destroy queue instance.

int	tryPush (const Type &element) noexcept
	try to push element into ring buffer.

int	push (const Type &element) noexcept
	push element into the ring buffer.

int	tryPop (Type &element) noexcept
	try to pop element from the ring buffer.

int	pop (Type &element) noexcept
	pop element from the ring buffer.

uint64_t	pending () const noexcept
	get the number of pending elements for reading.

uint64_t	available () const noexcept
	get the number of available slots for writing.

bool	full () const noexcept
	check if the ring buffer is full.

bool	empty () const noexcept
	check if the ring buffer is empty.

int	mbind (int numa) const noexcept
	bind memory to a NUMA node.

int	mlock () const noexcept
	lock memory in RAM.

Static Protected Member Functions
static uint64_t	roundPow2 (uint64_t v) noexcept
	round up to next power of 2.

Protected Attributes
uint64_t	_capacity = 0
	memory segment capacity.

uint64_t	_elementSize = 0
	memory segment element size.

uint64_t	_totalSize = 0
	total memory size.

Backend	_backend
	memory segment backend.

SyncPolicy	_policy
	memory segment sync policy.

QueueSegment< Type > *	_segment = nullptr
	shared memory segment.

Detailed Description

template<typename Type, typename Backend, typename SyncPolicy>
class join::BasicQueue< Type, Backend, SyncPolicy >

queue base class.

Member Typedef Documentation

◆ ValueType

template<typename Type , typename Backend , typename SyncPolicy >

using join::BasicQueue< Type, Backend, SyncPolicy >::ValueType = Type

Constructor & Destructor Documentation

◆ BasicQueue() [1/3]

template<typename Type , typename Backend , typename SyncPolicy >

template<typename... Args>

join::BasicQueue< Type, Backend, SyncPolicy >::BasicQueue	(	uint64_t	capacity,
		Args &&...	args )

inline

create instance.

Parameters

capacity	queue capacity.
args	backend args.

◆ BasicQueue() [2/3]

template<typename Type , typename Backend , typename SyncPolicy >

join::BasicQueue< Type, Backend, SyncPolicy >::BasicQueue ( const BasicQueue< Type, Backend, SyncPolicy > & other )

delete

copy constructor.

Parameters

other other object to copy.

◆ BasicQueue() [3/3]

template<typename Type , typename Backend , typename SyncPolicy >

join::BasicQueue< Type, Backend, SyncPolicy >::BasicQueue ( BasicQueue< Type, Backend, SyncPolicy > && other )

delete

move constructor.

Parameters

other other object to move.

◆ ~BasicQueue()

template<typename Type , typename Backend , typename SyncPolicy >

join::BasicQueue< Type, Backend, SyncPolicy >::~BasicQueue ( )

defaultnoexcept

destroy queue instance.

Member Function Documentation

◆ available()

template<typename Type , typename Backend , typename SyncPolicy >

uint64_t join::BasicQueue< Type, Backend, SyncPolicy >::available ( ) const

inlinenoexcept

get the number of available slots for writing.

Returns: number of slots available in the ring buffer.

◆ empty()

template<typename Type , typename Backend , typename SyncPolicy >

bool join::BasicQueue< Type, Backend, SyncPolicy >::empty ( ) const

inlinenoexcept

check if the ring buffer is empty.

Returns: true if empty, false otherwise.

◆ full()

template<typename Type , typename Backend , typename SyncPolicy >

bool join::BasicQueue< Type, Backend, SyncPolicy >::full ( ) const

inlinenoexcept

check if the ring buffer is full.

Returns: true if full, false otherwise.

◆ mbind()

template<typename Type , typename Backend , typename SyncPolicy >

int join::BasicQueue< Type, Backend, SyncPolicy >::mbind ( int numa ) const

inlinenoexcept

bind memory to a NUMA node.

Parameters

numa	NUMA node ID.

Returns: 0 on success, -1 on failure.

◆ mlock()

template<typename Type , typename Backend , typename SyncPolicy >

int join::BasicQueue< Type, Backend, SyncPolicy >::mlock ( ) const

inlinenoexcept

lock memory in RAM.

Returns: 0 on success, -1 on failure.

◆ operator=() [1/2]

template<typename Type , typename Backend , typename SyncPolicy >

BasicQueue & join::BasicQueue< Type, Backend, SyncPolicy >::operator= ( BasicQueue< Type, Backend, SyncPolicy > && other )

delete

move assignment operator.

Parameters

other other object to move.

Returns: this.

◆ operator=() [2/2]

template<typename Type , typename Backend , typename SyncPolicy >

BasicQueue & join::BasicQueue< Type, Backend, SyncPolicy >::operator= ( const BasicQueue< Type, Backend, SyncPolicy > & other )

delete

copy assignment operator.

Parameters

other other object to copy.

Returns: this.

◆ pending()

template<typename Type , typename Backend , typename SyncPolicy >

uint64_t join::BasicQueue< Type, Backend, SyncPolicy >::pending ( ) const

inlinenoexcept

get the number of pending elements for reading.

Returns: number of elements pending in the ring buffer.

◆ pop()

template<typename Type , typename Backend , typename SyncPolicy >

int join::BasicQueue< Type, Backend, SyncPolicy >::pop ( Type & element )

inlinenoexcept

pop element from the ring buffer.

Parameters

element output element.

Returns: 0 on success, -1 otherwise.

◆ push()

template<typename Type , typename Backend , typename SyncPolicy >

int join::BasicQueue< Type, Backend, SyncPolicy >::push ( const Type & element )

inlinenoexcept

push element into the ring buffer.

Parameters

element element to push.

Returns: 0 on success, -1 otherwise.

◆ roundPow2()

template<typename Type , typename Backend , typename SyncPolicy >

static uint64_t join::BasicQueue< Type, Backend, SyncPolicy >::roundPow2 ( uint64_t v )

inlinestaticprotectednoexcept

round up to next power of 2.

Parameters

v	input value.

Returns: smallest power of 2 >= v.

◆ tryPop()

template<typename Type , typename Backend , typename SyncPolicy >

int join::BasicQueue< Type, Backend, SyncPolicy >::tryPop ( Type & element )

inlinenoexcept

try to pop element from the ring buffer.

Parameters

element output element.

Returns: 0 on success, -1 otherwise.

◆ tryPush()

template<typename Type , typename Backend , typename SyncPolicy >

int join::BasicQueue< Type, Backend, SyncPolicy >::tryPush ( const Type & element )

inlinenoexcept

try to push element into ring buffer.

Parameters

element element to push.

Returns: 0 on success, -1 otherwise.

Member Data Documentation

◆ _backend

template<typename Type , typename Backend , typename SyncPolicy >

Backend join::BasicQueue< Type, Backend, SyncPolicy >::_backend

protected

memory segment backend.

◆ _capacity

template<typename Type , typename Backend , typename SyncPolicy >

uint64_t join::BasicQueue< Type, Backend, SyncPolicy >::_capacity = 0

protected

memory segment capacity.

◆ _elementSize

template<typename Type , typename Backend , typename SyncPolicy >

uint64_t join::BasicQueue< Type, Backend, SyncPolicy >::_elementSize = 0

protected

memory segment element size.

◆ _policy

template<typename Type , typename Backend , typename SyncPolicy >

SyncPolicy join::BasicQueue< Type, Backend, SyncPolicy >::_policy

protected

memory segment sync policy.

◆ _segment

template<typename Type , typename Backend , typename SyncPolicy >

QueueSegment<Type>* join::BasicQueue< Type, Backend, SyncPolicy >::_segment = nullptr

protected

shared memory segment.

◆ _totalSize

template<typename Type , typename Backend , typename SyncPolicy >

uint64_t join::BasicQueue< Type, Backend, SyncPolicy >::_totalSize = 0

protected

total memory size.

The documentation for this class was generated from the following file:

core/include/join/queue.hpp
