basic endpoint class. More...

#include <endpoint.hpp>

Public Types
enum	Side { A , B }
	endpoint side identifier. More...

using	Outbound = typename OutboundPolicy::Producer

using	Inbound = typename InboundPolicy::Consumer

Public Member Functions
constexpr	BasicEndpoint () noexcept
	default constructor.

	BasicEndpoint (const struct sockaddr *addr, socklen_t len) noexcept
	create instance using socket address.

struct sockaddr *	addr () noexcept
	get socket address.

const struct sockaddr *	addr () const noexcept
	get socket address.

	BasicEndpoint (Side side, const std::string &name, uint64_t elementSize=1472, uint64_t capacity=144)
	create instance.

	BasicEndpoint (const BasicEndpoint &other)=delete
	copy constructor.

BasicEndpoint &	operator= (const BasicEndpoint &other)=delete
	copy assignment operator.

	~BasicEndpoint ()
	destroy the instance.

int	open ()
	open the channel endpoint.

void	close ()
	close the channel endpoint.

bool	opened () const
	check if the endpoint is open.

int	trySend (const void *element)
	try to send a message to the peer (non blocking).

int	send (const void *element)
	send a message to the peer (blocking).

template<class Rep , class Period >
int	timedSend (const void *element, std::chrono::duration< Rep, Period > timeout)
	send a message to the peer with timeout (blocking).

int	tryReceive (void *element)
	try to receive a message from the peer (non blocking).

int	receive (void *element)
	receive a message from the peer (blocking).

template<class Rep , class Period >
int	timedReceive (void *element, std::chrono::duration< Rep, Period > timeout)
	receive a message from the peer with timeout (blocking).

uint64_t	available () const
	get number of available slots for sending.

bool	full () const
	check if outbound queue is full.

uint64_t	pending () const
	get number of pending messages.

bool	empty () const
	check if inbound queue is empty.

Side	side () const
	get the side this endpoint represents.

const std::string &	name () const
	get the channel name.

uint64_t	elementSize () const
	get the element size.

uint64_t	capacity () const
	get the buffer capacity.

Protected Attributes
struct sockaddr_storage	_addr = {}
	socket address storage.

Detailed Description

template<typename OutboundPolicy, typename InboundPolicy>
class join::BasicEndpoint< OutboundPolicy, InboundPolicy >

basic endpoint class.

bidirectional shared memory communication endpoint.

Member Typedef Documentation

◆ Inbound

template<typename OutboundPolicy , typename InboundPolicy >

using join::BasicEndpoint< OutboundPolicy, InboundPolicy >::Inbound = typename InboundPolicy::Consumer

◆ Outbound

template<typename OutboundPolicy , typename InboundPolicy >

using join::BasicEndpoint< OutboundPolicy, InboundPolicy >::Outbound = typename OutboundPolicy::Producer

Member Enumeration Documentation

◆ Side

template<typename OutboundPolicy , typename InboundPolicy >

enum join::BasicEndpoint::Side

endpoint side identifier.

Enumerator
A	side A acts as outbound producer and inbound consumer.
B	side B acts as inbound producer and outbound consumer.

Constructor & Destructor Documentation

◆ BasicEndpoint() [1/4]

template<typename OutboundPolicy , typename InboundPolicy >

join::BasicEndpoint< OutboundPolicy, InboundPolicy >::BasicEndpoint ( )

inlineconstexprnoexcept

default constructor.

◆ BasicEndpoint() [2/4]

template<typename OutboundPolicy , typename InboundPolicy >

join::BasicEndpoint< OutboundPolicy, InboundPolicy >::BasicEndpoint	(	const struct sockaddr *	addr,
		socklen_t	len )

inlinenoexcept

create instance using socket address.

Parameters

addr	socket address.
len	socket address length.

◆ BasicEndpoint() [3/4]

template<typename OutboundPolicy , typename InboundPolicy >

join::BasicEndpoint< OutboundPolicy, InboundPolicy >::BasicEndpoint	(	Side	side,
		const std::string &	name,
		uint64_t	elementSize = 1472,
		uint64_t	capacity = 144 )

inline

create instance.

Parameters

side	role of this endpoint.
name	channel name.
elementSize	the size of each data element in the ring buffers.
capacity	the maximum number of elements the ring buffers can hold.

◆ BasicEndpoint() [4/4]

template<typename OutboundPolicy , typename InboundPolicy >

join::BasicEndpoint< OutboundPolicy, InboundPolicy >::BasicEndpoint ( const BasicEndpoint< OutboundPolicy, InboundPolicy > & other )

delete

copy constructor.

Parameters

other other object to copy.

◆ ~BasicEndpoint()

template<typename OutboundPolicy , typename InboundPolicy >

join::BasicEndpoint< OutboundPolicy, InboundPolicy >::~BasicEndpoint ( )

inline

destroy the instance.

Member Function Documentation

◆ addr() [1/2]

template<typename OutboundPolicy , typename InboundPolicy >

const struct sockaddr * join::BasicEndpoint< OutboundPolicy, InboundPolicy >::addr ( ) const

inlinenoexcept

get socket address.

Returns: socket address.

◆ addr() [2/2]

template<typename OutboundPolicy , typename InboundPolicy >

struct sockaddr * join::BasicEndpoint< OutboundPolicy, InboundPolicy >::addr ( )

inlinenoexcept

get socket address.

Returns: socket address.

◆ available()

template<typename OutboundPolicy , typename InboundPolicy >

uint64_t join::BasicEndpoint< OutboundPolicy, InboundPolicy >::available ( ) const

inline

get number of available slots for sending.

Returns: number of free slots in the outbound queue.

◆ capacity()

template<typename OutboundPolicy , typename InboundPolicy >

uint64_t join::BasicEndpoint< OutboundPolicy, InboundPolicy >::capacity ( ) const

inline

get the buffer capacity.

Returns: number of elements each buffer can hold.

◆ close()

template<typename OutboundPolicy , typename InboundPolicy >

void join::BasicEndpoint< OutboundPolicy, InboundPolicy >::close ( )

inline

close the channel endpoint.

◆ elementSize()

template<typename OutboundPolicy , typename InboundPolicy >

uint64_t join::BasicEndpoint< OutboundPolicy, InboundPolicy >::elementSize ( ) const

inline

get the element size.

Returns: size of each message element in bytes.

◆ empty()

template<typename OutboundPolicy , typename InboundPolicy >

bool join::BasicEndpoint< OutboundPolicy, InboundPolicy >::empty ( ) const

inline

check if inbound queue is empty.

Returns: true if no messages available.

◆ full()

template<typename OutboundPolicy , typename InboundPolicy >

bool join::BasicEndpoint< OutboundPolicy, InboundPolicy >::full ( ) const

inline

check if outbound queue is full.

Returns: true if cannot send without blocking.

◆ name()

template<typename OutboundPolicy , typename InboundPolicy >

const std::string & join::BasicEndpoint< OutboundPolicy, InboundPolicy >::name ( ) const

inline

get the channel name.

Returns: channel name.

◆ open()

template<typename OutboundPolicy , typename InboundPolicy >

int join::BasicEndpoint< OutboundPolicy, InboundPolicy >::open ( )

inline

open the channel endpoint.

Returns: 0 on success, -1 on failure

◆ opened()

template<typename OutboundPolicy , typename InboundPolicy >

bool join::BasicEndpoint< OutboundPolicy, InboundPolicy >::opened ( ) const

inline

check if the endpoint is open.

Returns: true if both outbound and inbound queues are opened.

◆ operator=()

template<typename OutboundPolicy , typename InboundPolicy >

BasicEndpoint & join::BasicEndpoint< OutboundPolicy, InboundPolicy >::operator= ( const BasicEndpoint< OutboundPolicy, InboundPolicy > & other )

delete

copy assignment operator.

Parameters

other other object to copy.

Returns: assigned object.

◆ pending()

template<typename OutboundPolicy , typename InboundPolicy >

uint64_t join::BasicEndpoint< OutboundPolicy, InboundPolicy >::pending ( ) const

inline

get number of pending messages.

Returns: number of messages waiting in inbound queue.

◆ receive()

template<typename OutboundPolicy , typename InboundPolicy >

int join::BasicEndpoint< OutboundPolicy, InboundPolicy >::receive ( void * element )

inline

receive a message from the peer (blocking).

Parameters

element pointer to buffer for received element.

Returns: 0 on success, -1 on failure.

◆ send()

template<typename OutboundPolicy , typename InboundPolicy >

int join::BasicEndpoint< OutboundPolicy, InboundPolicy >::send ( const void * element )

inline

send a message to the peer (blocking).

Parameters

element pointer to the element to send

Returns: 0 on success, -1 on failure.

◆ side()

template<typename OutboundPolicy , typename InboundPolicy >

Side join::BasicEndpoint< OutboundPolicy, InboundPolicy >::side ( ) const

inline

get the side this endpoint represents.

Returns: Side::A or Side::B.

◆ timedReceive()

template<typename OutboundPolicy , typename InboundPolicy >

template<class Rep , class Period >

int join::BasicEndpoint< OutboundPolicy, InboundPolicy >::timedReceive	(	void *	element,
		std::chrono::duration< Rep, Period >	timeout )

inline

receive a message from the peer with timeout (blocking).

Parameters

element	pointer to buffer for received element.
timeout	maximum time to wait

Returns: 0 on success, -1 on failure.

◆ timedSend()

template<typename OutboundPolicy , typename InboundPolicy >

template<class Rep , class Period >

int join::BasicEndpoint< OutboundPolicy, InboundPolicy >::timedSend	(	const void *	element,
		std::chrono::duration< Rep, Period >	timeout )

inline

send a message to the peer with timeout (blocking).

Parameters

element	pointer to the element to send
timeout	maximum time to wait

Returns: 0 on success, -1 on failure.

◆ tryReceive()

template<typename OutboundPolicy , typename InboundPolicy >

int join::BasicEndpoint< OutboundPolicy, InboundPolicy >::tryReceive ( void * element )

inline

try to receive a message from the peer (non blocking).

Parameters

element pointer to buffer for received element.

Returns: 0 on success, -1 on failure.

◆ trySend()

template<typename OutboundPolicy , typename InboundPolicy >

int join::BasicEndpoint< OutboundPolicy, InboundPolicy >::trySend ( const void * element )

inline

try to send a message to the peer (non blocking).

Parameters

element pointer to the element to send

Returns: 0 on success, -1 on failure.

Member Data Documentation

◆ _addr

template<typename OutboundPolicy , typename InboundPolicy >

struct sockaddr_storage join::BasicEndpoint< OutboundPolicy, InboundPolicy >::_addr = {}

protected

socket address storage.

The documentation for this class was generated from the following files:

core/include/join/endpoint.hpp
core/include/join/shared.hpp
